2
~10K Hz
1000V Range ,1000V
AC/DC Max.
2500V Range ,2500V
AC/DC Max.
DC mA
0-50uA-0.5mA-
5mA-50mA-
500mA(10A)
 3% FSD.
 4% FSD for
10A
Drop Voltage: 250 mV
Overload protected by
Fuses 0.5A/250V &
10A / 250V at 10A
range, Max. test time
10sec. for 10A.
Ω
X 1: 0.2 ~ 2KΩ
Midscale at 20Ω
X 10: 2 ~ 20KΩ
Midscale at 200Ω
X 100: 20 ~ 200KΩ
Midscale at 2000Ω
X1K: 200~ 2MΩ
Midscale at 0KΩ
X10K: 2K ~20MΩ
Midscale at 200KΩ
 4% of ARC of
Scale Length
Overload protected by
the voltage Suppressor
& Fuse (3sec.)
Capacitance
(uF)
Cx1: 50uF
Cx10: 500uF
Cx100: 5000uF
Cx1K & Cx10K:
Approx. Value
Approx. Value
Overload protected by
the voltage Suppressor
& Fuse (3sec.)
BATT Check
0 -1.2V- 1.5V-
2.0V-3V-3.6V: BAD
(red)- ? –
GOOD(green)
 5% of ARC of
Scale Length
Overload protected by
the voltage Suppressor
& Fuse (3sec.)
Transistor
Check
hFE: 0-1000 via
special hFE socket
Approx. Value
At Ω X 10 Range
LED, Diode
Check
via special hFE
socket
Approx. Value
At Ω X 10 Range
Decibel
-22 dB ~ + 62 dB
Approx. Value
At ACV ranges
