Pro's Kit MT-2207 - INTRODUCTION; SPECIFICATION

1
INTRODUCTION
This Multi-meter is an accurate, safe handheld meter that comes with mirrored
Aluminum dial, robust protective holster alongside, built-in stand and hook-up
design. MT-2027 is powered by batteries, offers accurate, reliable measurement
of DC/AC Voltage, +/-DCV, DC Current, Resistance and Diode, LED, Transistor,
Decibels, Continuity test and Capacitance with very high sensitivity quality
movement.
This meter is designed with double-sided glass-epoxy PCB, full overload &
misused protection via two Fuses, voltage Suppressor & Diodes, and smart
protection on Ω testing via the extra Resettable Fuse & Varistor. Ideal for indoor
use in laboratory, school, workshop, and home applications.
SPECIFICATION
Safety Category: IEC61010-1, CAT II 1000V CAT III 500V and Pollution Degree 2.
Common Environment: 23C5C, less than 75% RH.
Operating temperature: 0C to 40C, 32 F to 104 F
Storage temperature: -10 C to 50C, 14 F to 122F
Operating Humidity Scope: Less than 90% RH.
Storage Humidity Scope: less than 80% RH.
Dimensione: 179(L) x 118(W) x 50(H) mm
Weight: 400g approx. (not including test leads and batteries)
Accessories: One pair of test leads;
Spare Fuse: F0.5A 250V;F10A 250V, Φ5x20mm
Test
Functions
Range
Accuracy
Remarks
DC V
0-0.25-1-2.5-10-
50-250-500-
1000V(2500V)
 3% FSD.
 4% FSD for
1000V(2500V)
Input Impedance:
20KΩ/V, UP 50V
9KΩ/V; Overload
Protection:
0.25V/1V/2.5V/10V/50
V Range，250V Max.
250V/500V/1000V
Range, 1000V AC/DC
Max.
2500V Range, 2500V
AC/DC Max.
AC V
0-10-50-250V-
500V
-1000V(2500V)
 4% FSD.
 5% FSD for
1000V(2500V)
Input Impedance:
9KΩ/V
Overload Protection:
10V/50VRange, 250V
Max. Band width: 40
