Proaction CJ021 - Assembly Instructions; Connecting Hose and Tube; Attaching Cleaning Heads

4
5
IMPORTANT:
Please read the important safety
instructions before use.
fig. 1
fig. 2
fig. 3
fig. 4
ASSEMBLY
NOTE: Always remove the plug
from the mains power before
fitting or removing accessories.
ASSEMBLY
1. Insert the Hose Connector C into
the Hose Inlet S until it clips
securely into position. (To remove
the Vacuum Hose from the
Vacuum Cleaner, press the Fitting
Hook D then pull upwards.)
See fig. 1.
3. Attach the end of the Suction Tube
A to the Hose Handle F of the
Vacuum Hose B.
See fig. 3.
4. Fit the Floor Head I onto the end
of the Extension Tube H.
See fig. 4.
5. Upholstery Head L and Crevice
Nozzle K are stored inside the
Vacuum Cleaner Body V.
Depending on the cleaning task,
Upholstery Head L and Nozzle K
can either be fitted to the Extension
Tube H or directly onto the
Handle.
S
D
C
A
H
2. Rotate the Extension Tube H
clockwise and pull out to desired
length. Lock it by rotate anti-
clockwise ensuring it is securely
located. 
See fig. 2.
H
I
F
A
Fitting the Heads
