2.2 INSTALLATION / OPERATION
1. Power cord：
Connect power to 100V~240VAC single phase power.
2. Power switch (SW1)：
I = On，O = Off
3. Forward / Reverse switch (SW2)：
Reverse ( ) / Forward ( )
4. Stop：
Press the Stop button to pause all motion and disable all control.
Rotate the Stop button clockwise to reset.
5. Speed Adjustment Knob (VR1)：
Rotate clockwise to increase speed, counter clockwise to decrease speed.
6. Foot switch (F.S)：
The foot switch is alternative type switch pressing it once and release would activate the roller.
Pressing it the second time to stop the roller.
7. Fuse holder (Fuse)：
Overload protection.
