ProArc TR-0103 - Main Wheel Adjustment Procedure

5
2.3 MAIN WHEEL ADJUSTMENT PROCEDURE
Step 1：
Step 2
：
Step 3
：
Use 17mm wrench and adjust
the nut in clockwise direction until
the PU roller moves.
Press the rollers with approximate
20-30 kg pressure and check for any
slip on the PU rollers.
Start the machine, then adjust
the speed to 50%.
