Section 2: Installation of Receiver and Transmitter Batteries
Receiver Batteries
1. Lift the cockpit off the boat from the rear.
2. Remove the clear lid on the radio box.
3. Remove the dry cell battery holder from the radio box and
unwrap the foam from around the dry cell battery holder. Install
4 AA alkaline batteries as shown. Note the proper polarity. Wrap
the battery box in foam.
4. Re-install the battery holder into the radio 8box and secure the
radio box. Be sure the antenna wire is extended through the
antenna tube.
Transmitter Batteries
1. Remove the transmitter from the box.
2. Remove the battery cover on the bottom of the transmitter.
3. Note the proper polarity and insert 4 AA batteries into the
transmitter.
4. Secure the batteries using the battery cover.
5. Turn on the radio and confi rm that all LEDs illuminate, indicating
proper installation of fully charged batteries.
6. Turn the radio off.
