Open window and clean frame and
casement surfaces of dust and particles.
Stick the velcro tape around the entire
window frame. Never stick to the window
seal as doing so will prohibit the window
from closing fully.
Stick the velcro tape around the entire
window casement (inside or outside).
Check to ensure the window can close
fully.
Attach side A of the sealing fabric
assembly to the velcro on the window
frame working from the centre outwards.
Close and open window to ensure no
fabric gets trapped.
Attach side B of the sealing fabric
assembly to the velcro on the window
casement working from the centre
outwards.
Open the window slightly and insert the
heat exhaust hose short connector into
the sealing fabric assembly securing with
the zippers around its lip.
The sealing fabric assembly is now ready
for use.
Notes:
•
•
Do not bend the heat exhaust hose in
excess of 45 degrees. It should be as short
and as straight as possible to ensure
efficient air flow.
Do not overstretch the heat exhaust hose as
this may affect the appliances efficiency
Hinged Window Sealing Fabric
Assembly Installation
1.
2.
3.
4.
5.
6.
7.
8.
Frame
Side A
Side B
Casement
7
4 & 6
2 & 3
Hinged window sealing fabric zip
09 | English
