Fig. 8 - Rough Opening for Installing in Corner
IMPORTANT: When nishing your rebox, combustible
materials such as wall board, gypsum board, sheet rock,
drywall, plywood, etc, must have ½ -in. clearance to the sides
and top of the rebox. Combustible materials should never
overlap the rebox front.
WARNING: Do not allow any combustible materials to
overlap the rebox front.
WARNING: Do not allow combustible or noncombustible
materials to cover any necessary openings like louvered
slots.
WARNING: Never modify or cover the louvered slots on
the front of the rebox.
Step 1
Step 3
Step 2
Fig 9
Remove two
screws on top
rebox panel
Insert three
screws on
hood
Assembling Hood
CAUTION: Do not operate replace without hood in place.
1. Fireplace hood is positioned on top of shipping inner pack.
2. Remove top of rebox by unscrewing two screws located
on each end. Insert the hood along the upper side of the
heat insulation board (see Fig. 9). Attach the hood with
3 screws. Re-attach the rebox top by re-inserting the two
screws.
