Procom FIB100 - Step 5: Connect temperature sensor and wire; Step 6: Remove left side panel; Step 7: Remove blower access panel

6
5.Connecttemperaturesensor(C)with
connectwire(D.Installthecover
accordingtoFigure2,thenxtheupper
reboxaccordingtoFig.1.SeeFig.5.
Fig.5
6.Unscrewandremovepanelontheleft
side.SeeFig.6.(ForModel#CRHFD32RT-M-
MO(Item#0293807),FBD32seriesonly)
Fig.6
Fig.7
D
C
7.Removebloweraccesspanel.SeeFig.7.
(ForPC32VFCandPC36VFCseriesonly)
