Procom FIB100 - Step 11: Mount blower onto access panel; Step 12: Attach power cord to top cover; Step 13: Affix grounding terminal

8
Fig.12
Fig.11
12.Attachthepowercord(A)tothereplace
withM4.2X8screws(AA)onthetop
cover.SeeFig.12.
Hardware Used
M4.2X8screws
x3
AA
AA
A
Fig.13
13.AfxthegroundingterminalwithM4.2X8
screw(AA).SeeFig.13.
Hardware Used
M4.2X8screw
x1
AA
AA
11.Mountblowerontobloweraccesspanel.
SeeFig.11.(ForPC32VFCandPC36VFC
seriesonly).
