www.usaprocom.com
31
200045-01A
PARTS
MODEL ML250TPA
This list contains replaceable parts for your heater. When ordering replacement parts, follow
the instructions listed under Replacement Parts on page 32 of this manual.
ITEM PART # DESCRIPTION QTY
1 MB10052 Cabinet Assembly 1
2 MB09051 Lower Front Panel 1
3 MB11051 Reector Unit 1
4 MB19002 Burner Assembly 1
5 SIT545-000-B Thermostat Valve Assembly 1
6 ML111-01A Thermostat Valve Base 1
7 845-4.8-60Z Self Tapping Screw 2
8 MB060-01 Mounting Bracket 1
9 MB40007 Thermostat Outlet Tube 1
10 ML096-01 4-way Connector 1
11 ML115-01 4-way Connector Bracket 1
12 ML116-01 4-way Connector Fixed Nut 1
13 ML073-01 Ignitor Cable 1
14 ND1808-800-9 ODS Pilot 1
14-1 ND0803-8 Thermocouple 1
14-2 ND0807 Ignitor Electrode 1
15 ML026-01 ODS Mounting Bracket 1
16 ML069-02 Self Tapping Screw 14
17 MB40008 ODS Gas Line Assembly 1
18 MB40009 Burner Gas Line Assembly C 1
19 MB40012 Burner Gas Line Assembly C1 1
20 MB40013 Burner Gas Line Assembly C2 1
21 MB40010 Burner Gas Line Assembly B 1
22 MB40014 Burner Gas Line Assembly B1 1
23 MB40015 Burner Gas Line Assembly B2 1
24 MB40011 Burner Gas Line Assembly A 1
25 ML090-02 Injector 5
26 ML056-01 "T" Joint 2
27 MB40006 Main Inlet Tube Assembly 1
28 NRV81FI-10 Pressure Regulator 1
29 96-4Z Washer 2
30 ML079-01 Self Locking Screw 2
31 MB29001 Grill Guard 1
32 ML083-03 Ignitor 1
33 ML105-01 ODS Deector 1
PARTS AVAILABLE - NOT SHOWN
MB28001 Hardware Package 1
ML065-01 Thermostat Sensing Bulb Clip 2
