13
8HPX1200/2400/2800Malfunction Analysis on SMPSCONTROL
Circuit
8.1CircuitDiagramofSMPSCONTROL
8.2MalfunctionAnalysisonSMPSCONTROLModuleCircuit
Sequence
No.
Circuit
Function
Failure
1 SMPSControl
‐ Theequipmentisunavailabletostart;
‐ Protectionfunctionwillbeactivatedwheninlowimpedanceoutput;
‐ Cyclicprotectionoftheswitchpower;
‐ Delay start, over‐voltage PROT, low‐voltage PROT and over current
PROT.
RepairingGuide:
1)Whenrepairingthecontrolboard,youcancuteveryprotectcircuitgraduallyfoundthedefective
area!
