PROEL MQ12USB User Manual

14
53. AC~ socket
Here’s where you plug in your mixer’s mains supply cord. You should always use the mains cord supplied with
the mixer.
Be sure your mixer is turned off before you plug the mains supply cord into an electrical outlet.
54. FUSE holder
Here is placed the mains protection fuse.
• CHECK THE CONDITION OF THE PROTECTION FUSE, ACCESSIBLE OUTWARD, ONLY WITH THE
APPARATUS SWITCHED OFF AND DISCONNECTED FROM THE MAINS LINE OUTLET.
• REPLACE THE PROTECTION FUSE ONLY WITH SAME TYPE AS SHOWN ON THE PRODUCT.
• IF AFTER THE SUBSTITUTION, THE FUSE INTERRUPTS AGAIN THE APPARATUS WORKING, DO
NOT TRY AGAIN THEN CONTACT THE PROEL SERVICE CENTER.
TECHNICAL SPECIFICATION
Type
Data
Connectors
Mic Input 1-8
sensitivity
from -10 to -50 dB
Balanced XLR-F
impedance
2 Kohm
Line Input 1-8
sensitivity
from +20 to -20 dB
Balanced JACK
impedance
10 Kohm
Lo cut
75Hz, 18dB/oct.
EQ
HIGH (shelving)
±15 dB @ 12KHz
MID (peaking)
±15 dB @ 2.5KHz
LOW (shelving)
±15 dB @ 80Hz
Compressor 1-4
1 control knob
Line Input 9-12
sensitivity
-10 dB
Balanced JACK, RCA
impedance
10 Kohm
MAIN MIX output
nom. out level
+4 dBu
Balanced JACK and XLR-M
GROUP 1-2 output
nom. out level
+4 dBu
Balanced JACK
C. ROOM output
nom. out level
0 dBu
Unbalanced JACK
AUX 1 / 2 output
nom. out level
0 dBu
Unbalanced JACK
HEADPHONES output
min. impedance
32 ohm
Stereo JACK
max. out level
(2x) 193 mW
Effects
100 presets
A/D and D/A converters
24 bit
DSP resolution
24 bit
Controls
2-DIGIT display, DIAL, PEAK LED, MUTE
switch, MUTE footswitch
Maximum level
all outputs
+22 dBu
Crosstalk
meas. at 1 KHz
> 82 dB
HUM & Noise
unweighted
< -93 dBu
THD + Noise
at +4dB, 1kHz
< 0,008 %
Dimensions (WxHxD)
346 x 355 x 95 mm
Weight
4,50 kg
Mains Supply Voltage
110-240 VAC (±10%) 50 / 60 Hz
available with:
Europe mains cord (Shucko plug),
US mains cord (NEMA 5-15P plug),
UK mains cord (BS1363 plug)
Consumption
35 W
