10.2.3. Interfaces

NOTICE
Please be aware that the measured performance values were determined in the free field without
significant interference or signal dampening. The maximum range, latency and the possible
message throughput may vary considerably depending on the environmental influences, setup
condition, the used antennas and, if applicable, the hardware installed for the WLAN
infrastructure. Please consider these values just as approximate reference values which can be
achieved in a specific test setup under ideal conditions. It is the system integrators responsibility
to verify the connection stability and performance under real ambient conditions as part of the final
application and setup.
Table 51. Interfaces
Parameter Value
CAN interfaces 2 (no galvanic isolation)
CAN specification
CAN, CANopen (ISO 11898-2:2016, SAE J2284-
1, SAE J2284-5),CAN-FD (CiA 601-4)*
Max. CAN baud rate 1 Mbit/s (CAN, CANopen)
4 Mbit/s (CAN-FD CiA 601-4)*
Digital OUT 1 digital output
- Terminal 30 switching 6 VDC … 36 VDC
- max. output current: 500 mA
- max. switch frequency: 10 Hz
- Overvoltage protection up to 36 VDC
- Reverse voltage protection up to -36 VDC
- incl. diagnostic and analog read back of output voltage
Analog IN 2 analog inputs
- Measurement range: 0 VDC to 15 VDC
- Input resistance: 20 kOhm
- Resolution: 12 bit
- Sampling rate: 20 Hz
- Overvoltage protection up to 36 VDC
- Reverse voltage protection up to -36 VDC
- Tolerance: ± 1 % of measurement range end value (at
25 °C)
Terminal 15 Analog input
- Measurement range: 0 VDC to 36 VDC
- Input resistance: 20 kOhm
- Resolution: 12 bit
- Sampling rate: 20 Hz
- Overvoltage protection up to 36 VDC
- Reverse voltage protection up to -36 VDC
- Tolerance: ± 1 % of measurement range end value (at
25 °C)
- Low-to-High Transition Wakes up the device from
SleepMode
Operating modes Interface & Bridge mode in Bluetooth or WLAN
mode
Bluetooth Standard Bluetooth classic (2.1+ EDR) and V5.0 with
long range support (Bluetooth LE)*
WLAN Standard IEEE 802.11a/g
IEEE 802.11b
IEEE 802.11n
WLAN encryption WPA/WPA2 Mixed, PEAP* (*upcoming firmware)
WLAN transmission rate IEEE 802.11a: to 54 Mbit/s
IEEE 802.11b: to 11 Mbit/s
IEEE 802.11g: to 54 Mbit/s
IEEE 802.11n: to 65 Mbit/s
