Serial
No.
Description Q’ty
Serial
No.
Description Q’ty
1 Worktable 1 17 Screw M8X16 6
2
Low connection of
worktable
1 18 Leg 2
3 Screw M6x16 6 19 Foot 4
4
Thrust ball
bearing
1 20 Joint pin of wallboard 3
5 Screw M6X16 4 21
Right junction plate
of motor
1
6
Up connection of
Motor
1 22 Screw M6X20 4
7 Motor 1 23
Deep groove ball
bearing
1
8
Left junction plate
of motor
1 24 Right shaft sleeve 1
9 Screw M6X20 4 25
Components of right
wall
2
10
Deep groove ball
bearing
1 26 Right connection 1
11
Reinforcing
sleeve
1 27 Screw M6X12 3
12 Left shaft sleeve 1 28
Adjustable locking
hand shank
1
13 Left wallboard 1 29 Cover 1
14 Left connection 1 30 Screw M8X70 1
15 Screw M6X16 3 31 Nut M6 8
16 Flat gasket 6
