PROFAX WP220 - Main Specification; Operation Instruction

3. Main specification
Item No. 378381 378382 378383
Model WP220 WP350 WP500
Horizontal
loading capacity
220 kg 350 kg 500 kg
Vertical loading
capacity
100 kg 120 kg 250 kg
Table dia. 330 mm 330 mm 550 mm
Table height 450 mm 480 mm 660 mm
Rotation Speed 0-5 rpm 0-5 rpm 0-5 rpm
Tilt angle 0-135° 0-135° -45°~90°
Tilt by Manual Manual Electric
Rotation motor 125 W 125 W 400 W
Packing size 64x49x63 cm 64x44x63 cm 82x73x71 cm
N.W./G.W. 34/48 kg 38/52 kg 220/245 kg
4. Operation instruction
4.1 Adjust of WP220/WP350
4.1.1 Adjust revolve of worktable
 Power on the machine, the worktable revolves when
step on foot switch; stop revolve when loosen foot
switch.
 The worktable’s positive and negative rotation can be
controlled by the rotary knob on top of electric box.
Turn knob clockwise, worktable rotate positive;
