Tri Stem
6
01
02
03
TORQUE SETTINGS
1 Bar clamp bolts M5x18mm 1Nm (8.8 inlbf)
2Steerer clamp bolts M5x18mm 5Nm (44 inlbf)
3 Headset cap bolt M3x10mm 6Nm (53 inlbf)
Ref.# Location Bolt Size Torque
