7
FOLDING THE ARMS
1. Fold the front arms backwards until they sit close to the body of the
drone.
2. Fold the rear arm down until it is parallel to the body.
DO NOT FORCE THE ARMS AWAY FROM THE BODY AS THIS
MAY RESULT IN DAMAGE.
REPLACEMENT OF THE PROPELLERS
Should one of the fitted propellers become damaged, it can be
replaced, by removing the screw from the top of the propeller
before sliding the propeller off the motor shaft. Refitting is the
reversal of removal.
It is important for the correct blade to be placed on the correct
motor or the aircraft will not fly correctly. Each blade is marked
with an A or B on the top to indicate which motor it corresponds
to.
