ProFlight PFBD302 - Battery Installation; Controller Diagram

8
INSTALLING THE CONTROLLER BATTERIES
Unclip the battery covers from the rear of the controller and insert 3 x AA
batteries, making sure the correct polarity is followed. Once the batteries
are correctly installed, the battery cover must be re-fitted. (Batteries not
supplied)
CONTROLLER DIAGRAM
Power indicator
One Button Return
Direction Lever
One Button Take
Off/ One Button
Land
Compass Calibration
Speed Mode
Switching
Gyro Calibration
Press Once to Take a
Photo/Press and Hold
to Take a Video.
Power Button
(Access by opening
the middle panel)
