ELECTRICAL CONNECTIONS
Caution
Electrical compartment contains live terminals, please e
nsure supply is isolated before
removing the cover. Any person accessing this part of the unit should be suitably trained and
competent.
Before carrying out any maintenance work, disconnect the drive and the external control
circuits from the power supply by moving the main system switch to “off”. Once power has
been disconnected from the drive, wait at least 5 minutes before disconnecting the
elec t r ical c ab les .
QUIETCO2OL MT
QUIETCO2OL LT series
Q
C
30M
T
Q
C
45M
T
QC QC
67MT 100MT
QC
75LT
QC
112LT
QC
167LT
Power sup
ply
230 V / Single phase
/ 50 Hz
+ G
400 V / 3ph /50 Hz
N + G
230 V / Single
phase /
50 Hz
400 V / 3 ph /
50 Hz N + G
Max.
absor
bed
current
without
13,3 A
18,7 A
27,2 A 18,5 A 18,4 A
17,5 A
31,4 A
Max. absorbed
cu
rrent wit
hout
evaporato
rs
(Water cooled)
12,5 A
19,9 A
26,4 A 16,5 A 17,6 A
17,5 A
31,4 A
If consumers are powered from the condensing unit using the available circuit breakers, select
the main power supply by adding the actual consumer input current to the above values
General infor matio n
– The machine is designed in accordance with EN60204-1.
– Supplying cable must be connected on terminal of main switch.
– All cabling on site must conform to the legal standards in force in
the relevant countries and to EN60204-1.
