ProGear 300LS - Right and Left Handrail Arms Installation

5. Right and Left Foot Pedals Installation:
Attach the Right Foot Pedal (19R) onto the top of the right side Foot Pedal Support Bracket (18)
located on the Right Foot Bar (17) with two Bolts (20) and two Nylon Nuts (14). Tighten the
Nylon Nuts (14) using the Open-Ended Flat Wrench provided.
Attach the Left Foot Pedal (19L) onto the top of the left side Foot Pedal Support Bracket (18)
located on the Left Foot Bar (76) with two Bolts (20) and two Nylon Nuts (14). Tighten the Nylon
Nuts (14) using the Open-Ended Flat Wrench provided.
H
ardware:
(20) Bolt
4PCS
(14) Nylon Nut
4PCS
16
ASSEMBLY
Tools:
Open-Ended Flat Wrench
