Progressive Dynamics PD1600 Series User Manual

15
Troubleshooting
Troubleshooting Guide
Symptom Corrective Actions
E-5 is displayed
During startup the inverter draws a small amount of current to charge the input capacitors. If that current exceeds a normal
range the inverter shuts down and reports an internal error. This is can be indicative of bad input wiring or an internal failure.
 Ensure all DC input connections are tightened
 Make sure DC input wire size and length comply with Figure 15
E-6 is displayed
A short circuit has been detected on the AC output of the inverter.
 Check the AC wiring to make sure that wires aren’t touching each other
 Check each AC load for failure
 Determine surge requirements for AC loads. Motorized loads may draw peak power greater than the peak power rating
Inverter is off. Noth-
ing happens with
power button is
pressed
Likely, DC Input power is not being properly applied to the DC input terminals.
 Ensure all DC input connections are tightened
 Ensure that all any external DC disconnect switches are in the on position
 Ensure that the DC input wires are connected to positive and negative correctly (not reversed)
 If using the remote display panel, make sure that it is connected to the inverter using the provided 25’ cable.
Inverter turned off for
seemingly no reason
Something has interrupted the communication between the display and the inverter.
 Ensure that the equipment ground wire is properly secured to the equipment ground lug
For Further Assistance Contact:
PDI Service Department:
service@progressivedyn.com
WARNING: FIRE, SHOCK, OR ENERGY HAZARD
DO NOT disassemble the inverter. It does not contain any user service-
able parts. Attempting to service the unit yourself could result in an
electrical shock or burn.
Failure to follow these instructions may result in serious injury or
death.
*All ratings at 25 °C unless otherwise listed
SPECIFICATIONS
PHYSICAL SPECIFICATIONS TRANSFER SWITCH
PD1610 PD1618 PD1620 PD1610 PD1618 PD1620
Dimensions
L:11.2”(284mm)
W:6.7”(170mm)
H:4.0”(101mm)
L:15.0”(381mm)
W:7.9”(200mm)
H:4.0”(101mm)
L:15.0”(381mm)
W:7.9”(200mm)
H:4.0” (101mm)
Transfer Voltage 95 - 135 VAC
Transfer Time < 50 msec
Net Weight 7 lbs (3.2 kg)
11 lbs (5.0 kg) 11 lbs (5.0 kg)
Pass Through
Ampacity
20 AAC
AC OUTPUT DC INPUT
PD1610 PD1618 PD1620 PD1610 PD1618 PD1620
Waveform Pure Sine Wave Nominal Voltage 12.0 VDC
Output
Voltage
120
VAC
Under-Voltage
Shutdown
10.5
VDC
Max Power
(Cont)
1000W
1800W 2000W
Under-Voltage
Restart
12.0 VDC
Max Power
(Peak)
2000W
3600W 4000W
Over-Voltage
Shutdown
15.5 VDC
Frequency 60 Hz
Over-Voltage
Restart
15.0 VDC
Peak
Efficiency
90%
Max Current @
max load
100 ADC 180 ADC 200 ADC
