7
The PD1600 Series Inverter in a 50A RV Power System
PD52 SERIES
TRANSFER SWITCH
MAIN NEUTRAL SUB NEUTRAL
12V
Battery Bank
PD60 SERIES
DC DISTRIBUTION PANEL
MAIN
SUB
PD55B006
AC DISTRIBUTION PANEL
GROUND
GROUND
TO DC LOADS DC GROUND
GROUND
TO AC LOADS (HOT)
(SHORE/GENERATOR ONLY)
TO AC LOADS (HOT)
(SHORE/GENERATOR/INVERTER)
20A 20A
50A
15A
GENERATOR
PD9200
SERIES
CONVERTER
SHORE
CONNECTION
PD1600 SERIES
INVERTER
AC IN
AC OUT
DC+
DC-
