Progressive Dynamics PD1610 - 50 A RV Power System Wiring Diagram

Consult a licensed electrician or RV technician for installation assistance 814420H
Installation Template
Figure 10 Remote Display Mounting Template
[69.89] 2.75
[57.15] 2.25
MOUNTING
HOLE
MOUNTING
HOLE
[101.64] 4.00
[85.85] 3.38
[73.03] 2.87
(Full Scale)
