Consult a licensed electrician or an RV technician for installation assistance
Page 3
TROUBLESHOOTING GUIDE
Specifications
(Specifications subject to change without notice)
Model
PD4045 PD4060
AC Section
120 VAC 30 Amps Maximum - 7 Branch Circuits Max *
DC Section
Converter
Section
Input: 105-130 VAC 50/60 Hz
725 Watts
Output: 13.6 VDC,
45 Amps
Weight: 5.70 lbs
Input: 105-130 VAC 50/60 Hz
1000 Watts
Output: 13.6 VDC,
60 Amps
Weight: 6.35 lbs
12 VDC 60A Max. - 12 Branch Circuits 12 VDC 75A Max - 12 Branch Circuits
AC RATING
COPPER WIRE ONLY. RATED 75 C MIN
MAXIMUM SERVICE: 30 AMPS, 120V 50/60 HZ SINGLE PHASE
LINE TERMINALS SIZE 6-14 AWG
LOAD TERMINALS SIZE 6-14 AWG
NEUTRAL AND GROUND SIZE 6 - 14 AWG
SHORT CIRCUIT CURRENT RATING:
SUITABLE FOR USE ON NO MORE THAN
120 VOLTS AC, 10,000 AMPERES MAX,
LIMITED TO THE LOWEST INTERRUPTING
CAPACITY OF ANY BREAKER INSTALLED
NEUTRAL/GND WIRE COMBINATIONS:
(1) #12 STRANDED & (1) #14 SOLID
(1) #12 STRANDED & (1) #14 STRANDED
(1) #12 SOLID & (1) #14 STRANDED
(1) #12 SOLID & (1) #14 SOLID
(2) #14 STRANDED OR (2) #14 SOLID
(2) #12 STRANDED OR (2) #12 SOLID
(2) #10 STRANDED OR (2) #10 SOLID
MAXIMUM CONTINUOUS LOADS ON
MAINS OR BRANCH CIRCUITS NOT TO
EXCEED 80% OF THE CIRCUIT
BREAKER RATINGS
TORQUE DATA
LINE TERMINAL: SEE CIRCUIT BREAKER
NEUTRAL BAR & GROUND:
#4 - #6 35 IN. LBS
#8 30 IN. LBS
#10 - #14 25 IN. LBS
PROBLEM POSSIBLE CAUSES
ACTION
No Output
120 VAC supply not connected
Connect power supply
Check AC distribution panel for proper operation
Reverse battery fuses blown
Check for reverse battery connection.
(See page 2 for location)
Replace fuses with same type and rating (See page 2)
Short circuit
Trace RV circuits for possible fault
Unit has shutdown due to overheating
Check air flow
Allow unit to cool
Unit has shutdown due to over voltage Check input voltage
(Converter will shut down if the input voltage exceeds 132 VAC)
Correct input voltage
Low Output
Check air flow to the converter
Improve ventilation to the compartment
Excessive load for converter
Reduce load requirements or install larger converter
Input voltage not between 105-130 VAC
Correct input supply voltage
Bad battery cell(s)
Replace battery
Intermittent or no Output
on Generator, works on
Shore Power
Unit has shutdown due to over voltage.
Add another load to the generator, this may reduce the “spikes” to an
acceptable level
Some generators exhibit excessive voltage spikes on
the AC power output, this may cause the over voltage
protection to shut the unit down
Contact generator manufacturer for possible defect in the generator
Compartment gets too hot
* Consult local regulatory authority for possible branch circuit restrictions
