Owner’s Handbook Page 11
compreSSor air Filter
electrical SyStem
timer / toggle Switch
air preSSure check
operatioN teSt
• Replace inlet air filter annually or more often
if dusty conditions are encountered.
• Check the internal and the external wire harnesses for damage. Replace if required.
• Refer to Service Bulletin SB0049 ’Annual Servicing Instructions for X45 Ignition Lead and Ignition Coil‘.
• Check to see that both operate as described in the Operation Manual.
• Correct air pressure is important – refer to the X45 Plus Service manual 925860 for further information.
• Run the system for at least 15 minutes
or until the heater cycles “OFF”
and then “ON” again.
• Alternate the thermostat
for the sleeper heater
(if connected) between
the lowest and highest
settings to ensure that
the sleeper heater fan
cycles “ON”and “OFF”.
Tor que to 50±5 In/Lbs (5.6±0.7 Nm)
Caring for your PROHEAT
Hose from CompressorHose to Nozzle Air Inlet
Digital Manometer PK0037
