PACKAGE CONTENTS
A
B
C
PART DESCRIPTION QUANTITY
A Faucet 1
B Aerator (preassembled) 1
C Main Plunger (preassembled) 1
D Lift Rod 1
E Drain Body (preassembled) 1
F Drain Flange (preassembled) 1
G Lift Rod Strap 1
H Thumbscrew (preassembled) 1
I Rubber Washer (preassembled) 1
J Lock Nut (preassembled) 1
K Friction Washer (preassembled) 1
L Spring Clip 1
M Ball Nut (preassembled) 1
N Ball Rod 1
O Bushing 1
L
E
K
F
J
I
M
D
H
G
N
O
