13
LED BATTERY CHARGE STATUS INDICATORS
SELECTED BATTERY CHEMISTRY LED DESCRIPTION
Constant Red FLASHING BLUE Output Reverse Polarity
Flashing Red FLASHING BLUE Output Overvoltage
Constant Amber FLASHING BLUE Output Open Circuit or Dead Battery
Flashing Amber CONSTANT BLUE Soft-start Timeout
Flashing Green CONSTANT BLUE Bulk Charging
Flashing Green FLASHING BLUE Absorption Charging
Constant Green FLASHING BLUE Equalisation Charging
Constant Green CONSTANT BLUE Float Charging (Charging Complete
or time out)
Constant Red ALL BATTERY MODE LED’S FLASHING Output Short Circuit
HOW TO SELECT BATTERY CHEMISTY
IDC25X allows you to select the select the appropriate charge setting for your
auxiliary battery.
To change the battery type, hold and press the Mode Button (
) for about 3
seconds. When the Charge LED turns OFF and the Battery Type LED will begin to
flash, then release Mode button. After which, Mode Button ( ) can be short
pressed to select the Battery Type. When the Battery Type LED is in the correct
Battery Chemistry for about 3 seconds, then that Battery Type chemistry is deemed
selected.
To confirm you have selected the correct battery chemistry, press the Mode button
(
).
OUTPUT OVERRIDE
If Auxiliary battery has been heavily discharged, hold and press the Mode button
(
) for about 10 seconds. When all Battery Type LEDS light up simultaneously, let
go of the Mode Button. This will cause IDC25X to commence charging.
