5
LIN BUS
Input
Terminal
Ignition
Input
Terminal
Temperature 1
Input
Terminal
Auxiliary LED Input Terminal
– Provision for auxiliary LED
to indicate IDCX status
Alternator
Input Post
Temperature 2
Input
Terminal
Power LED – Indicates
IDCX on/off charging status
Solar LED – Indicates
solar input status
Alternator LED – Indicates
alternator input status
Battery Chemistry
Setting LED
QR code - scan to show
instruction manual URL
and full series number
Ground Connection
Input Post
Solar Input Post
Auxiliary Battery
Input Post
PRODUCT OVERVIEW
137
122
50
IDC25X
