SPECIFICATIONS
P/No. IDC25X
Operating Conditions
Alternator Input Voltage 9-32V
Maximum Solar Input Voltage 32Vdc
Maximum Input Current 35A
Input Current (No Load) 8mA
Back Drain on Auxiliary Battery
INPUT: 9-11Vdc 20A
INPUT: 11-32Vdc 25A
External LED Output –
Constant Current
5mA
Input Fuse Rating 50A (Not supplied) – FK25A Recommended
Output Fuse Rating 50A (Not supplied) – FK25A Recommended
Maximum Output Power 360W
Size (mm) 137 x 122 x 50
Weight (g) 1180
Charge Control
Charge Type 5 Stage
Constant current up to
BULK *20A at 9-11Vdc, 25A at 11-32Vdc
GEL AGM WET CALCIUM LiFePO
4
14.1V 14.4V 14.7V 14.7V 14.2V
Absorption
Constant voltage until current drop to 3.8A:
GEL AGM WET CALCIUM LiFePO
4
14.1V 14.4V 14.7V 14.7V 14.2V
Float
GEL AGM WET CALCIUM LiFePO
4
13.7V 13.7V 13.7V 13.7V 13.5V
Equalisation (Calcium Mode &
Periodic Use Only)
2A Constant Current Charge up to 16V then hold for 30 min (5 hour timeout)
Battery Range
Battery Capacity Please check the battery user manual
Type of Batteries Supported GEL, AGM, WET, CALCIUM & LiFePO
4
Operating Mode
Vehicle Voltage Range 12Vdc 24Vdc
VSR Mode – Default (Ignition
Override Not Connected)
Turn On
13.4-16.5Vdc
Turn Off
<12.8Vdc
Turn On
26.8-32.0Vdc
Turn Off
<25.6Vdc
Low Voltage Mode – Ignition
Override cable connected to
ignition switch (Ignition On)
Turn On
12.2-16.5Vdc
Turn Off
<11.9Vdc
Turn On
24.4-32.0Vdc
Turn Off
<23.8Vdc
Output Current
Input 9-11Vdc 20A
Input 11-32Vdc 25A
Standards
EMC AS/NZS CISPR11 Class B, R10
IP Rating IP68 & IP69K
