Projecta INTELLI-CHARGE IDC25X - Product Overview

4
LIN BUS
Input
Terminal
Ignition
Input
Terminal
Temperature 1
Input
Terminal
Auxiliary LED Input Terminal
– Provision for auxiliary LED
to indicate IDCX status
Alternator
Input Post
Temperature 2
Input
Terminal
Power LED – Indicates
IDCX on/off charging status
Solar LED – Indicates
solar input status
Alternator LED – Indicates
alternator input status
Battery Chemistry
Setting LED
QR code - scan to show
instruction manual URL
and full series number
Ground Connection
Input Post
Solar Input Post
Auxiliary Battery
Input Post
PRODUCT OVERVIEW
137
122
50
138
122
71
IDCX
IDC25X IDC50X
