Projecta IP2000 - Product Overview; Front View; Rear View

5
REMOTE
12VDC INPUT
+
–
2000W Pure Sine Wave
240V a.c 50Hz input – Max connected output load = 2000W
Wiring to be carried out by licensed electrician.
Incorrect wiring will damage the unit and void warranty.
OUTPUTINPUT
OFF
ON
VOLTS ECOWATTS
LOAD%
SAFETY
SWITCH
TEST
OFF
ON
REMOTE
12VDC INPUT
+
–
2000W Pure Sine Wave
240V a.c 50Hz input – Max connected output load = 2000W
Wiring to be carried out by licensed electrician.
Incorrect wiring will damage the unit and void warranty.
OUTPUTINPUT
OFF
ON
VOLTS ECOWATTS
LOAD%
SAFETY
SWITCH
TEST
OFF
ON
Display
Selection
Buttons
LCD Screen RCD Safety
Switch
Remote
Input
MAINS AC
Input Terminals
Mounting
Holes
On/Off
Switch
AC Output
Sockets
Fan 12VDC
Positive
Terminal
12VDC
Negative
Terminal
AC Output
Terminals
FRONT VIEW
REAR VIEW
PRODUCT OVERVIEW
