20
Mnenomic Table Comments
IABS [0..2, 4..6] 0 – VGA 1
1 – VGA 2
2 – DVI
3 – YPbPr interlace
4 – S-Video
5 – Composite Video
6 – YPbPr progressive
Ignore other values returned, no source is
connected.
SABS[0..3, 9-10, 13-14] 0 – 1to1 (only VGA)
1 – fill all (only VGA)
2 – fill aspect ratio
3 – fill 16:9
9 – letterbox to 16:9
10 – letterbox subtitle to 16:9
13 – zoom (only Video)
14 – anamorphic
Use of other numbers may result in poor
picture quality, and is not recommended.
ORIE[0..3] 0 – Desktop front
1 – Ceiling rear
2 – Desktop rear
3 – Ceiling front
Command: AMX: Crestron:
Power ON ‘:POWR1’,$0d :POWR1\r
Power OFF address 100 ‘:’,$20’POWR’,$20,’0’,$0d :\x20100\x20POWR\x200\r
or or
‘:100POWR0’,$0d :100POWR0\r
or or
‘: 100 POWR 0’,$0d : 100 POWR 0\r
6.9 AMX/Crestron:
SPACE characters should be used with hex notation or left out to avoid confusion/errors.
6.10 Truth-tables for abs-values
