APPENDIX D, ADJUSTING CUSTOM COLOR TEMP USING RS232
D.1 Choose “Custom color temp”
Note: It is important to select ”custom color temp” before adjusting R/G/B temps, otherwise these commands will not work! All values are hexadecimal.
Select Color Temp Custom: BE EF 03 19 00 96 20 01 07 44 00 00 00 00 00 00 04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Other choices are:
Select Color Temp 6500: BE EF 03 19 00 34 A3 01 07 44 00 00 00 00 00 00 02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Select Color Temp 7300: BE EF 03 19 00 C5 E3 01 07 44 00 00 00 00 00 00 01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Select Color Temp 9300: BE EF 03 19 00 55 22 01 07 44 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
D.2 Adjust the color temperature by using the increment / decrement operations:
Red Temp Increment: BE EF 03 19 00 14 2B 03 16 40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Red Temp Decrement: BE EF 03 19 00 7A 81 04 16 40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Green Temp Increment: BE EF 03 19 00 81 76 03 17 40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Green Temp Decrement: BE EF 03 19 00 EF DC 04 17 40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Blue Temp Increment: BE EF 03 19 00 41 07 03 18 40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Blue Temp Decrement: BE EF 03 19 00 2F AD 04 18 40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
You may now bring the adjusted custom setting forward by selecting “custom color temp”, either through keypad/remote or via RS232.
