INSTALLATION INSTRUCTIONS
Step 1.
Unscrew two screws from each side, located behind the
side flanges. Keep them for later use.
Cauon: Do Not let front face panel fall forward once the
screws are removed. This could break the glass or lead to
damage or injury.
Step 2.
Gently lean the top of the face panel away from the body.
Make sure to support the face panel so it does not drop
totally forward. Unplug the wires that connect the control
panel.
Step 3.
Spread the Acrylic Shards onto the emberbed area.
Step 4.
Re-Install the face frame.
Align the front frame with the body, plug in the wire bundle
to the control panel. Install the four screws
To Next Page
