3
ECLIPSEFS
- 1 - INTRODUCTION
1.1 TECHNICAL DRAWING
Technical drawing Fig.1
259.4mm/
10,21mm
268.8mm/
10,58in
663.3mm/26,11in
ECLIPSEFS + OPTIC
