Fields settings on the second block:
Field Description
Rule Action
Deny or allow traffic when matching this rule.
Direction
Traffic bridging/forwarding direction.
Src MAC Address
The source MAC address. It must be xxxxxxxxxxxx format. Blanks can be
used in the MAC address space and will be considered as “don’t care”.
Dst MAC Address
The destination MAC address. It must be xxxxxxxxxxxx format. Blanks can
be used in the MAC address space and will be considered as “don’t care”.
Function buttons for the second block:
Apply Changes
Click to apply the rule entry to the configuration.
Function buttons for the Current Filter Table:
Delete Selected
Delete selected filtering rules from the Current Filter Table. You can click the checkbox at the
Select column to select the filtering rule.
Delete All
Delete all filtering rules from the Current Filter Table.
