7 / 25
Description
The C430BN consists of two main parts:
The body that contains the motors (one vacuum motor, two brush motors), cleaning solution
tank, recovery tank, handle and control panel with 3 functional buttons & one power display
window).
The scrub deck that contains the brushes and squeegee.
The C430BN can be folded into a park position; this is recommended for storage.
The C430BN consists of:
The main section of the top handle consists of:
1 Top handle 7 Surrounding fence
2 Recovery tank 8 Castor wheels
3 Scrub deck 9 Solution tank
4 Battery pack box knob 10 Carrying handle
5 Battery pack box 11 Squeegee assembly
6 Bumper wheels 12 Brushes
Speed Adjustment – for low “- “
Speed Adjustment – for low “+”
