TR515 User’s Manual
26
Appendix C. Cable
1. WAS-1436 ( For TR515WX/TR515SX RS-232 )
BLACK
ORANGE
GRAY
COLOR
YELLOW
GREEN
RED
RJ-11 8P8C PIN
1
2
3
4
5
6
DB 9P FEMALE PIN
7
2
8
3
NC
*
5
BROWN
BLUE 7
8
NC
*
NC
*
* NC - No Connect
WAS-1436
PIN1
PIN8
WAS-1436 : LENGH - 2000 mm , WIRE - 8P8C / AWG #28
2. WAS-1467 ( For TR515SX RS-485 )
RJ-11 8P8C PIN
1
2
3
4
5
6
WIRE
CUT*
CUT*
CUT*
CUT*
5
CUT*
7
8
7
CUT*
WAS-1467
BLACK
ORANGE
GRAY
COLOR
YELLOW
GREEN
RED
BROWN
BLUE
PIN1
PIN8
PIN7
PIN5
* CUT - Cut wire
WAS-1467 : LENGH - 2000 mm , WIRE - 8P8C / AWG #26
