TR515 User’s Manual
4
Red Led Green Led
POWER
JACK
BELL
CONNECTOR
10BaseT Port
TR515 CONNECTOR AND STATUS
TR515EX’s interface connector pin assignment can be found in Appendix B.
3. Wireless Interface Versions
The TR515WX designed to operate in the 433MHz ISM (Industrial, Scientific
and Medical) frequency band. It features Frequency Shift Keying (FSK)
modulation and demodulation capability.
You must purchase a Master station RDL401A to connect with PC
Wireless Communication
RDL401A
