Identity code ordering system
Identity code ordering system
Please enter the identity code on the device label into the grey box below.
S3Ca Sigma Control Type (S3Ca)
H Main drive, diaphragm
Pump type: (figures 1+2 = back pressure [bar], figures 3-5 = feed rate [l/h]):
120145* 12 bar; 174 l/h
120190* 12 bar; 228 l/h Note:
120270* 12 bar; 324 l/h 60 Hz performance data apply
070410 7 bar; 492 l/h for S3Ca pump types
070580 7 bar; 696 l/h (due to internal 60 Hz operation).
040830 4 bar; 1000 l/h * for PVDF max. 10 bar
Liquid end material:
PVT PVDF
SST Stainless steel
Positive displacement element:
0 Standard diaphram, PTFE version
1 Double diaphragm with rupture indicator incorporating “Pump stopping” function
2 Double diaphragm with rupture indicator incorporating “Pump alarm” function
Liquid end version:
0 No valve springs
1With 2 valve springs, Hastelloy C 4: 0.1 bar (standard for DN 32)
4With bypass valve, Viton
®
seal, no valve springs
5With bypass valve, Viton
®
seal and valve springs (standard for DN 32)
Hydraulic connector:
0 Standard thr eaded connector (as technical data)
1 Union nut and PVC insert
2 Union nut and PP insert
3 Union nut and PVDF insert
4 Union nut and stainless steel insert
7 Union nut and PVDF hose nozzel
8 Union nut and stainless steel hose nozzel
Version:
0 With ProMinent
®
logo (standard)
1 Without ProMinent
®
logo
Power supply:
A1 ph 200-230 V ±10 %, 50/60 Hz
B1 ph 100-115 V ±10 %, 50/60 Hz
W1 ph 115-230 V ±10 %, 50/60 Hz
Lead and plug:
A2 m Europe
B2 m Switzerland
C2 m Australia
D2 m USA
Relay:
0 No relay
1 Fault indicating relay N/C
3 Fault indicating relay N/O
4 As 1 + pacing relay
5 As 3 + pacing relay
F power relay N/C
G power relay N/O
Control variants:
0 Manual + external with pulse control
1 Manual + external with pulse control + analogue
4 as 0 + process-timer
5 as 1 + process-timer
P PROFIBUS
®
Access code:
0 No access code
1 With access code
Metering monitor:
0 Input with pulse evaluation
1 Input with continuous contact evaluation
Stroke length adjustment:
0 Manual
C Manual + calibration
S3Ca _ _ _ ___________
