SmartStor NAS Quick Start Guide
30
Setting up a Network Drive on a Mac
Before you can access the SmartStor from a Mac (Mac OS X) PC, you must
configure the SmartStor to communicate with the Mac OS X.
FOR NAS SERVER
In WebPASM
1. Start WebPASM.
See “From browser directly” on page 19 or “Connect WebPASM from
SmartNAVI” on page 19.
2. Click the Administration topic and choose the File & Print icon to expand
the Tree. (A)
3. Click the Protocol Control icon (B), then click the Mac tab. (C)
4. Click the Enable button (D).
5. Optional. Type a message in the Login Message field. (E)
6. Click the OK button to save your settings. (F)
The optional login message appears on the Welcome screen when you log
into SmartStor from a Mac.
To set up Mac file sharing:
1. Click the Administration topic and choose the File & Print icon to expand
the Tree. (A)
2. Click the Sharing Setup icon (B), then click the Windows/Mac/FTP
Sharing tab. (C)
3. Choose a volume from the Volume dropdown menu. (D)
4. Choose a folder from the Folder Name dropdown menu. (E)
5. Check the Mac protocol box. (F)
6. In the User/Group list, group names are preceded by the @ character. (G)
7. Under Permissions, choose a permission level for this user or group: (H)
• Deny Access – Visible only, cannot open
• Read Only
• Read and Write – Default
To Next Page
