Managing Disk Arrays
219
6. Press the button. The disk status LED for the physical drive blinks for
one minute. See Figure 2.
Figure 2. Disk Status LED
Managing Disk Arrays
Disk Array Management in the LCD includes the following functions:
• Creating a Disk Array – Automatic (page 219)
• Creating a Disk Array – Advanced (page 220)
• Deleting a Disk Array (page 222)
• Viewing Disk Array Information (page 223)
• Locating a Disk Array (page 224)
• Creating a Logical Drive (page 224)
• Deleting a Logical Drive (page 225)
• Viewing Logical Drive Information (page 226)
• Locating a a Logical Drive (page 227)
For other disk array functions, see “Managing Disk Arrays” on page 114
(WebPAM PROe) or page 158 (CLU).
For other logical drive functions, see “Managing Logical Drives” on page 127
(WebPAM PROe) or page 172 (CLU).
Creating a Disk Array – Automatic
The Disk Array Automatic Creation option enables you to create a new disk array
following a default set of parameters. One logical drive will be made automatically
when you create the disk array.
If you have multiple enclosures, a separate disk array and logical drive set will be
created for each enclosure.
If you have both Hard Disk Drives (HDD) and Solid State Drives (SSD), separate
disk array and logical drive sets will be created for your HDDs and for your SSDs.
These two drive types cannot be mixed in the same disk array.
Disk Status
