Dropout / Derailleur hanger
The dropout and derailleur hanger need to be tightened using 12
Nm / 8,9 ft lb.
The rear X-12 axle needs to be tightened using 10-16 Nm / 7,38-
11,8 ft lb.
Shock
The M8 bolt screws of the shock need to be tightened using 18 Nm
/ 13,28 ft lb.
General recommendation M4-M8
You can find general recommendations in the following
table in case there are no other instructions on spare
parts. Propain also recommends using Loctite 243 (me-
dium) to secure those screws.
Size of the screw
Tightening torque
M4
3 Nm / 2,21 ft lb
M5
6 Nm / 4,42 ft lb
M6
9 Nm / 6,64 ft lb
M8
18 Nm / 13,28 ft lb
Shock
The Rage frame is compatible with most of the shocks available on
the market (with the correct length and travel). Nevertheless, there
are exemptions which is why Propain always recommends a check
of compatibility when installing a new shock into the bike.
Compatibility check
When installing another shock into the bike, you have to make sure
it is compatible with the frame. The first important point is to check
the specifications of the new shock.
It needs to have the following specifications:
Shock length: 241mm
Shock travel: 76mm
Shock hardware top and bottom: 22,2mm x 8mm
If the specifications are identical, the shock can be installed into the
bike to check if there are any points of contact when riding the bike.
Points of contact could damage the bike severely, which in the worst
case could lead to a crack in the frame and / or a crash when riding
the bike.
