ProsKit MT-1280 - Technical Characteristics Overview; AC Voltage (ACV) Measurement Data; DC Current (DCA) Measurement Data

3
• 1000V DC or AC peak value at other ranges.
2-2-2. ACV
RANGE ACCURACY RESOLUTION
2V
±(0.8%+5d)
1mV
20V 10mV
200V 100mV
750V ±(1.2%+10d) 1V
• Input resistance: 10MΩ
• Overload protection: 1000V DC or AC peak value
• Frequency response: (40~200)Hz
• Display: sine wave RMS (mean value response)
2-2-3.DCA
RANGE ACCURACY RESOLUTION
200uA ±(0.8%+10d) 0.1uA
20mA 10uA
200mA ±(1.2%+8d) 100uA
20A ±(2.0%+5d) 10mA
• Max. input volt drop: 200mV
• Max. input current: 20A (the test time should be in 10
seconds)
• Overload protection: 0.2A/250V; 20A/250V fast-blown fuse
