• CHARACTERISTIC
1. GENERAL
1-1. Displaying: LCD displaying.
1-2. Max. displaying: 1999(3 1/2digit) auto polarity indication.
1-3. Measuring method: dual slope A/D conversion.
1-4. Sampling rate: approx. 3 times/second.
1-5. Overrange indication: the MSD displays"1" or "-1".
1-6. Low battery indication:"
" appears.
1-7. Operation environment: (0~40)˚C, R.H.<80% .
1-8. Power: 9V×1(NEDA1604/6F22 or equivalent model)
not included.
1-9. Size: 190×90×50mm
1-10. Weight: approx. 335g (Without Battery).
2. TECHNICAL CHARACTERISTIC
2-1. Accuracy: ±(a%×rdg+d) at (23±5)<R.H.<75%
2-2. TECHNICAL DATA
2-2-1. DCV
RANGE ACCURACY RESOLUTION
200mV
±(0.5%+3d)
100uV
2V 1mV
20V 10mV
200V 100mV
1000V ±(0.8%+10d) 1V
• Input resistance: 10MΩ for all ranges.
• Overload protection: 250V DV or AC peak value at 200mV range.
