5
2-2-6. CAPACITANCE (C)
RANGE ACCURACY RESOLUTION
20nF ±(2.5%+20d) 10pF
2uF 1nF
200uF ±(5.0%+10d) 100nF
• Overload protection: 36V DC or AC peak value
2-2-7.TEMPERATURE(˚C)
Range Accuracy Resolution
(-20~1000)˚C < 400˚C±(1.0%+5d)
≥ 400˚C±(1.5%+15d)
1˚C
• Sensor: K-type thermocouple with banana plug
2-2-8.DIODE AND CONTINUITY TEST
Range Displaying value Test condition
Positive voltage drop
of diode
The positive DC current
is approx. 1mA, negative
voltage is approx. 3V
Buzzer sounds , the
resistance is less than
(70±20)Ω
open voltage is approx.
3V
• Overload protection: 250V DC or AC peak value
Warning: DO NOT input any voltage at this range for
safety!
