ProsKit MT-3109 - Specifications; General and Environmental Specifications

MT-3109 AC/DC Digital Clamp Multimeter
C. Resistance
Range Resolution Accuracy
Overload
protection
400.0Ω 100mΩ +(1.2%+5)
4.000kΩ 1Ω
40.00kΩ 10Ω
400.0kΩ 10Ω
+(1 %+5)
4.000MΩ 1kΩ +(1.2%+5)
40.00MΩ 10kΩ +(1.5%+5)
600Vp
D. Diode Test
Range Resolution Accuracy Overload
protection
1mV Display forward
voltage drop
nearest value
600Vp
Remark: Open circuit voltage approximate 1.48V.
E. Continuity Test
Range resolution accuracy Overload
protection
100mΩ Around≤50Ω
The buzzer beeps
600Vp
Remark:
Open circuit voltage approximate 0.45V.
 The buzzer may or may not beeps when the resistance of a
circuit under test is between 50Ω~1OOΩ
 The buzzer will not beep when the resistance of a circuit under
test is > 1OOQ.
17
