Proteus EEC-1500 - Parts List

key D 'ty
escription Q
33 Foam grip (D) 1
34 M10 bolt x 15mm 2
35 M10 bolt x 55mm 2
36 M10 spring washer 4
37 Protective cover (L) 1
38 Protective cover (R) 1
39 3/16" (4.8mm) screw x 38mm 4
40 3/8" (9.5mm) bolt x 70mm 4
41 3/8" (9.5mm) dome nut 4
42 3/8" (9.5mm) washer 4
43 M6 screw x 40mm 6
44 M6 washer 6
45 Handlebar end cap 2
46 M6 socket screw x 40mm 6
47 M6 dome nut 6
48 M6 cone washer 12
49 M5 screw x 10mm 4
50 M5 screw x 10mm 2
51 Tension control 1
52 Adjust tube 2
53 Sleeve 4
54 Knob 1
55 Connecting bracket 1
56 5/32"(4.0mm) screw x 16mm 2
57 3/8" (9.5mm) bolt x 50mm 2
58 3/8" (9.5mm) nut 2
59 C-clip 2
60 Wire holder 2
61 3/8" (9.5mm) bolt x 50mm 4
62 Plastic plate 2
63 Axle spacer 2
64 Power transformer 1
key D 'ty
escription Q
1 Main frame 1
2 Front stabilizer 1
3 Rear stabilizer 1
4 Pedal arm (L) 1
5 Pedal arm (R) 1
6 Handlebar (L) 1
7 Handlebar (R) 1
8 Rest handlebar (L) 1
9 Rest handlebar (R) 1
10 Pedal (L) 1
11 Pedal (R) 1
12 Monitor 1
13 Connecting arm (L) 1
14 Connecting arm (R) 1
15 Cross joint-front 2
16 Cross joint-rear 2
17 Handlebar post 1
18 Wheel 2
19 Foot cap 2
20 Pivot end cap 2
21 Disk (L) 1
22 Disk (R) 1
23 Chain cover (L) 1
24 Chain cover (R) 1
25 30 x 60 plug 4
32 Foam grip (C) 1
26 Extension wire 1
27 Sensor wire 1
28 Pulse wire 2
29 Extension pulse wire 1
30 Extension monitor cable 1
31 Motor 1
PARTS LIST
- 8 -
