It is design to work with air heaters PROTON.
Automatic or manual fan speed adjustment.
Possibility to operate with RC 30 remote controller.
Possibility of operation with door switch DC 230.
It controls room temperature (by opening/closing the valve,
or by adjusting air volume).
Antifreeze mode – protection against dropping room
temperature below critical level.
Possibility to connect NTC 65 external temperature sensor.
1. GENERAL DESCRIPTION
Fan speed adjustment
Power supply 230 VAC/50 Hz
Regulation Buttons/LCD display
Storage temperature
–10 ... +60°C
Ambient temperature range
IP 20
0 ... +50°C
Installation Wall
Casing Plastic
Weekly timer 5+1+1
Rated switching power
450 W
Setpoint Range
+5 ... +70°C
Temperature sensor
Internal built-in/external
NTC 65 (optional)
3 speeds + AUTO mode
2. TECHNICAL DATA
22
RTS 40 programmable controller RTS 40 programmable controller
